One system processes round tubes, square and rectangular tubes, as well as open profiles such as channels, angles, and I-beams, expanding application range and maximizing return on investment.
41ft
Max. Processable Tube Length
2700lb
Max. Tube Weight
41ft
Max. Finished Part Length
60RPM
Max. Chuck Rotational Speed
2400IPM
Max. Rapid Traverse Speed
Supports continuous processing and automatic loading/unloading of full-length tubes, ideal for long parts and high-volume production.
The loading and unloading area features a fully enclosed structure, enhancing operational safety and improving the workshop environment.
Camera-based weld seam recognition automatically identifies weld seam locations, ensuring cutting accuracy and consistent finished part appearance.
Optional bevel cutting enables multi-angle bevel processing, reducing secondary operations and improving overall fabrication efficiency.
Through coordinated three-chuck control and optimized processing logic, zero-remnant cutting can be achieved under defined operating conditions, maximizing material utilization and reducing scrap.
